LS7232

touch control lamp dimmer, LSI Computer Systems, DIP, 50Hz/60Hz line frequency, Phase-lock loop synchronization, +20 V

Rated 5 Rating 5 | reviews | Write a review

Price:: US $3.20~4.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $3.20~4.00

PartNumber:: LS7232

Brand:: LSI Computer Systems - LC | Pack: DIP | D/C: 06+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Ouyang's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-04-25

From Other Seller

Part Number:LS7232
US $3.20 - 4.00
A50L-0001-0175

US $100.00 - 100.00 / Piece
(0) Remove
HT46R47

US $0.35 - 1.50 / Piece
(0) Remove
Quantity:

piece

Product Summary

The LS7232 is a monolithic, MOS integrated circuit designed for the control of brightness of incandescent lamps. The outputs of these ICs control the brightness of a lamp by controlling the firing angle of a triac connected in series with the lamp. All internal timings are synchronized with the line frequency by means of a built-in phase-lock loop circuit. The output occurs once every half-cycle of the line frequency. Within the halfcycle, the LS7232 output can be positioned anywhere between 158°conduction angle for maximum brightness and 41 conduction angle for minimum brightness in relation to the AC line frequency. The positioning of the output is controlled by applying a low level at the SENS input or a high level at the EXT input.

Parametrics

LS7232 absolute maximum ratings: (1)DC Supply Voltage VSS: +20 V; (2)Any Input Voltage VIN: VSS -20 to VSS + 0.5 V; (3)Operating Temperature TA: 0 to +80 ℃; (4)Storage Temperature TSTG: -65 to +150 ℃.

Features

LS7232 features: (1)Phase-lock loop synchronization allows use in Wall Switch applications; (2)Provides brightness control of incandescent lamps with touch plates or mechanical switches; (3)Controls the duty cycle from 23% to 88%; (conduction angles for AC half-cycles between 41 and 158 respectively.); (4)Operates at 50Hz/60Hz line frequency; (5)Extension input for remote activation.; (6)Input for slow dimming.; (7)+12V to +18V DC Power Supply voltage. (VSS - VDD).
